AnywhereUSB® - Netzwerkfähiger USB Hub

Der AnywhereUSB von Digi ist ein Netzwerkfähiger USB Hub.
Der AnywhereUSB von Digi ist ein Netzwerkfähiger USB Hub.
Die Netzwerkfähigen USB Hubs der AnywhereUSB® Serie von Digi sind ausgestattet mit SSL, SNMPv3, 2 - 14 USB Ports, 1 oder 2 10/100 Base-T Ethernet Ports und ermöglicht die Steuerung der USB Geräte über das Netzwerk.


zum Merkzettel hinzufügen

Datenblatt zusenden


AnywhereUSB® - Network-Attached USB Hubs

AnywhereUSB products are network-attached USB hubs that connect USB peripheral devices to a PC over a Local Area Network. The AnywhereUSB TS model also adds four RS-232 serial ports, enabling the mixing of USB and serial ports over the same network connection. Relocating the host PC to a remote location translates to smaller workstations, enabling deployment without a local PC in kiosks, ATMs, restaurant kitchens, manufacturing lines or any hostile or non-secure area where having a local PC is not practical.

AnywhereUSB is a network-attached USB hub. Combining Digi's patented RealPort® USB and RealPort® COM port redirector technologies, AnywhereUSB connects USB and serial devices anywhere on a wired or wireless LAN, while eliminating the need for locally-attached host PCs. Relocating the host PC to a remote location translates to smaller workstations, enabling deployment without a local PC in kiosks, ATMs, restaurant kitchens, manufacturing lines or any hostile or non-secure area where having a local PC is not practical.

AnywhereUSB/2, AnywhereUSB/5 and AnywhereUSB TS provide two, five and four USB ports respectively, which deliver the same Plug and Play user experience as onboard USB ports. AnywhereUSB TS also adds four RS-232 serial ports with the same transparency. Software drivers are loaded onto a host PC or server, enabling remote devices to communicate with the host, without changing existing application software. Peripheral devices can be centrally managed and monitored from a remote server or PC via an IP address.

AnywhereUSB is compatible with bulk or interrupt type USB devices such as bar-code scanners, printers, fingerprint scanners, mice, pole displays, card readers, flash drives, security keys, and more. It is an excellent solution for networked USB or serial devices in VMware and Microsoft virtualized environments. Watchport/V3 USB camera, Watchport® sensors and Edgeport® USB-to-serial converters are also fully compatible with AnywhereUSB.

Features
IP Address1 static (fixed) address per unit
LEDsSystem and Port status
ManagementCLI and AnywhereUSB web configuration tool
Other Shared FeaturesRemote configuration utility; Multiple units supported per server; Field-upgradable software and firmware; Patented RealPort (serial over IP) and RealPort USB (USB over IP)
USB Downstream Power500 mA per USB device
USB CompatibilityUSB 1.0, 1.1, 2.0 Note: USB storage devices and USB modems are not supported. Digi’s Edgeport/1 USB-to-serial converter may be used to connect a serial modem.
Operating SystemsWindows® 8, Windows 7, Windows Vista®, Windows Server® 2012 R2, Windows Server 2008 R2, Windows Server 2003, Windows XP®, Windows XP Embedded
Environmental
Storage Temperature-40° F to +185° F (-40° C to +85° C)
Relative Humidity0% to 95% (non-condensing)
Network and Device Recommendations
USB Device TypesCompatible with bulk or interrupt type USB devices; Isochronous devices not supported
Regulatory Approvals
SafetyUL 1950/CSA 2.2 No. 950, EN60950, IEC-950
Emissions/ImmunityCE, FCC Part 15 (Class B), EN55022, EN55024
AnywhereUSB/2
10/100Base-T Ethernet1 RJ-45
USB2
SerialN/A
Power SupplyShips with 120-240VAC 50-60 Hz at 5VDC @ 3 amps max w/ locking barrel
Serial Data RatesN/A
Multi-Host ConnectionsN/A
Dimensions (L x W x H)2.38 in x 3.9 in x 1.0 in (6.04 cm x 10.0 cm x 2.54 cm)
Weight5.0 oz (141.8 g)
Operating Temperature32º F to 140º F (0º C to 60º C)
Network Type10/100 Mb switched Ethernet
AnywhereUSB/5
10/100Base-T Ethernet1 RJ-45
USB5
SerialN/A
Power SupplyShips with 120-240VAC 50-60 Hz at 5VDC @ 3 amps max w/ locking barrel
Serial Data RatesN/A
Multi-Host ConnectionsN/A
Dimensions (L x W x H)4.35 in x 7.20 in x 1.03 in (11.05 cm x 18.29 cm 2.61 cm)
Weight10.0 oz (283.5 g)
Operating Temperature32º F to 140º F (0º C to 60º C)
Network Type10/100 Mb switched Ethernet
AnywhereUSB/5M
10/100Base-T Ethernet1 RJ-45
USB5
SerialN/A
Power SupplyShips with 120-240VAC 50-60 Hz at 5VDC @ 3 amps max w/ locking barrel
Serial Data RatesN/A
Multi-Host ConnectionsYes
Dimensions (L x W x H)4.35 in x 7.20 in x 1.03 in (11.05 cm x 18.29 cm 2.61 cm)
Weight10.0 oz (283.5 g)
Operating Temperature32º F to 140º F (0º C to 60º C)
Network Type10/100 Mb switched Ethernet
AnywhereUSB/TS
10/100Base-T Ethernet1 RJ-45
USB4
Serial4 RS-232 RJ-45
Power SupplyShips with 120-240VAC 50-60 Hz at 5VDC @ 3 amps max w/ locking barrel
Serial Data RatesUp to 230 Kbps per port
Multi-Host ConnectionsN/A
Dimensions (L x W x H)4.35 in x 7.20 in x 1.03 in (11.05 cm x 18.29 cm 2.61 cm)
Weight10.0 oz (283.5 g)
Operating Temperature32º F to 140º F (0º C to 60º C)
Network Type10/100 Mb switched Ethernet
AnywhereUSB/14
10/100Base-T Ethernet2 RJ-45
USB14
Serial1 RS-232 DB9
Power SupplyIncludes 2 120-230VAC 50-60 Hz @8 amps max
Serial Data RatesUp to 230 Kbps per port
Multi-Host ConnectionsYes
Dimensions (L x W x H)4.97 in x 17.00 in x 1.74 in (12.62 cm x 43.18 cm x 4.42 cm), Rack mountable 1U
Weight40 oz (1134 g)
Operating Temperature32° F to 131° F (0° C to 55° C)
Network TypeDual 10/100 Mb switched Ethernet
14-Port Model
AnywhereUSB/14 with Multi-Host Connections AW-USB-14-W
2-Port Model
AnywhereUSB/2 AW-USB-2-W
5-Port Model
AnywhereUSB/5 Gen 2 AW-USB-5-W
AnywhereUSB/5 with Multi-Host Connections AW-USB-5M-W
TS Model
AnywhereUSB TS - 4 serial and 4 USB ports AW-TS-44-W
